Mimaki UJV300DTF-75
$29,995.00
Precision MeetsProductivity DB00000-00 UV-DTF Printer UV-DTF in UV Transfer Printing
Description
New All-in-One UV-DTF Solution
The Mimaki UJV300DTF-75 printer is the company’s first purpose-built UV-DTF (direct-to-film) printer, designed to easily produce vibrant, durable transfers including curved or uneven surfaces using a dedicated film system. With stable media handling, next-generation UV inks, and user-friendly operation, it opens up new possibilities for customized goods production.
- Personalize objects unlimited by size or shape
- Compact and efficient
- Automated inline lamination
- No weeding required for faster production
- One-touch media loading
- Specialized film handling rollers
- Next generation UV curable inks
Our Core Technologies
Nozzle Check Unit
Nozzle Recovery System
Mimaki Circulation Technology
Mimaki Advanced Pass System
Waveform Control
Specifications
| Printhead | Two on-demand piezo heads |
| Print resolution | 1,200dpi max |
| Maximum Print Width | 25.2” (640mm) |
| Maximum media width | 25.6” (650mm) |
| Maximum Media Diameter | 9.84” (250mm) or less |
| Maximum Media Weight | 99 lbs (45 kg) or less |
| Ink Type | 4C+4SP (CMYK+WWClCl)
UV curable flexible ink ELS-170 CMYK UV curable hard ink ELH-100 White/Clear |
| Interface | Ethernet 1000 BASE-T / USB2.0 Hi-speed |
| Power Supply | AC100～120/200～240V±10％, 50/60Hz±1Hz×1 |
| Power Consumption | 100V – 1,440W or less, 200V – 1,920W or less |
| Operational Environment | Temperature: 68-86 F (20° – 30°C) Humidity: 35 – 65 % RH (Non condensing) |
| Dimensions (W × D × H) | 82” x 37” x 58” (2,090 × 930 × 1,475 mm) |
| Weight | 367 lbs (180kg) |
| Certifications | VCCI class A、FCC class A、IEC62368-1 ETL, CE Marking (EMC Directive, Low Voltage Directive, RoHS), CB report, ENERGY STAR, RCM, KC |
| *Specifications subject to change. |
Inks
| UV curable ink | Cyan | Magenta | Yellow | Black | White | Clear |
|---|---|---|---|---|---|---|
| ELS-170 (1 L) | X | X | X | X | ||
| ELH-100 (1 L) | X | X |
Additional information
| Printer | JFX200-2513, JFX200-2513 EX, JFX200-2531 |
|---|
