SpectroPlate

Description

The Techkon SpectroDens is a user‐friendly handheld spectrodensitometer that combines both a highly accurate spectrophotometer and a fast densitometer.

All three SpectroDens models come with a 2‐year factory warranty, charging console with integrated white standard, 3mm aperture, AC adapter with universal plugs, device case, USB‐cable, SpectroConnect software, and manual with ISO 9000 certificate.

SPECTROPLATE HIGHLIGHTS
MEASURES ALL TYPES OF PLATE MEDIA
Conventional & chemistry free plates, polyester and paper.

MEASURES ALL TYPES OF SCREENING
Including AM, FM and Hybrid form low to high resolutions.

LONG LASTING BATTERY
Up to 10,000 measurements per charge.

QC SOFTWARE INCLUDED
Build transfer curves and examine dot image captures.

ABILITY TO MEASURE WITHOUT COMPUTER CONNECTION
Measure, save and view up to 250 sample measurements without the need to be connected to a computer

Versions and functions
SpectroPlate is available in three different types of performance packages: The entry-level model, Start, is designed for dot percentage measurements on all popular types of printing plates, film and CMYK print. The Expert version additionally features the recording of complete transfer curves and the possibility to analyze geometric objects within the device. The All-Vision model is able to measure supplementary low-contrast, process-low printing plates. The Start version can easily be upgraded to an Expert model by a post-purchase upload from the PC. All-Vision functionality is achieved by a hardware expansion. All three types can easily be connected to the Windows software TECHKON SpectroConnect which is included in the package. All devices are factory-calibrated to a highly accurate reference printing plate resulting in high long-term absolute accuracy and an excellent inter-instrument agreement. Additionally, time-consuming calibration procedures prior to measurements are obsolete.

SpectroPlate Start
dot percentage, screen angle in screen frequency in l/cm and lpi

SpectroPlate Expert
Same functions as SpectroPlate Start and additionally:Dot % transfer curve, Dot gain transfer curve, Geometric analysis, Memory for 100 data sets, Average measurement

SpectroPlate All-Vision
Same functions as SpectroPlate Expert and additionally: Measurement of chemistry-low, process-low plates with very low visible contrast

Software TECHKON SpectroConnect requires Windows 7, 8 or 10
Contents SpectroPlate Measurement device, Charging console with white standard, AC adapter with universal plugs, USB cable, Data media with Windows software TECHKON SpectroConnect, Manual with ISO 9000 compliant certificate (pdf on data media), Manufacturer certificate
