Mimaki CJV330 Series

Mimaki CJV330 Series

Mimaki

$18,500.00 - $24,194.50

The Mimaki CJV330 Series are commercial-grade integrated eco-solvent print-and-cut systems for high-production sign and graphics work — available in 54" and 64" widths, with up to 1200 dpi, 100 m²/h print speeds, 8/10-color ink options, and a 3-roll media changer.

SKU:
CJV330
Applications:
produce vehicle wraps, custom decals, retail displays, posters, banners, and heat-transfer apparel graphics in a single, automated workflow
Adding to cart… The item has been added

The Mimaki CJV330 Series are advanced commercial-grade, integrated eco-solvent print-and-cut systems built for high-production sign and graphics businesses. Available in two sizes — 54" and 64" — they deliver high-definition resolution and fast turnaround for vehicle wraps, decals, banners, and posters.

Feature CJV330-130 (54") CJV330-160 (64")
Max Print/Cut Width 1,360 mm (53.5") 1,610 mm (63.4")
Max Media Width 1,370 mm (53.9") 1,620 mm (63.8")
Dimensions 115" × 47.8" × 51.4" 124.8" × 47.8" × 51.4"
Weight 363 kg (800.3 lbs) 373 kg (822.3 lbs)

Printing

  • Print head — two staggered on-demand piezo heads (6,400 total nozzles)
  • Resolutions — 600, 800, 900, and 1200 dpi
  • Max print speed — up to 100.0 m²/h (1,076 sq ft/hr) in 4-color mode
  • Ink types — eco-solvent (SS21, SS22, or BS4)
  • Color options — up to 8- or 10-color configurations, including Orange, Light Black, and White
  • 3M™ MCS™ Warranty — fully certified when using genuine SS21, SS22, or BS4 inks

Cutting

  • Max cutting speed — up to 300 mm/s
  • Cutting pressure — 10 to 450 gf
  • Functions — contour cutting, half-cut, die-cut, and V-shaped cut
  • Repeatability — ±0.2 mm (excluding film shrinkage/expansion from temperature)

Media handling & workflow

  • Media changer — holds up to three rolls at once for fast, single-operator switching
  • Max roll weight — 45 kg (99.2 lbs) per roll
  • Inline XY slitter — built-in sheet-fed cutting reduces post-processing trimming
  • Connectivity — Ethernet 1000BASE-T or USB 2.0 Hi-Speed

G7 Expert Certified Available through Alder Color Solutions, an authorized Mimaki dealer. Our G7-certified color experts can help you dial in accurate, repeatable color across your print-and-cut workflow.

Technical Specifications

Series Mimaki CJV330 (130 / 160) Type Integrated eco-solvent print & cut
Print Head 2 staggered on-demand piezo (6,400 nozzles) Resolutions 600 / 800 / 900 / 1200 dpi
Max Print Speed 100.0 m²/h (1,076 sq ft/hr), 4-color Ink Eco-solvent SS21, SS22, BS4; 8/10-color (Orange, Light Black, White)
Max Cutting Speed 300 mm/s Cutting Pressure 10–450 gf
Cutting Functions Contour, half-cut, die-cut, V-cut Repeatability ±0.2 mm
Media Changer Up to 3 rolls; 45 kg (99.2 lbs) max per roll Workflow Inline XY slitter
Connectivity Ethernet 1000BASE-T, USB 2.0 Hi-Speed Warranty Program 3M™ MCS™ certified (genuine inks)
Offered By Alder Color Solutions (authorized Mimaki dealer)
!
