The Mimaki CF22-1215 is a multifunction plotter built for the immediate finishing of packaging and prototypes. When combined with Mimaki's UV-LED tabletop flatbed printers and packaging design software, this system gives you the ability to easily and economically produce a wide variety of applications — from custom packaging to on-demand promotional goods — all in a compact, self-contained workflow.
Why shops choose the Mimaki CF22-1215:
- 20" x 24" cutting area — handle a wide range of packaging and prototype sizes
- Reciprocating, tangential, and eccentric cutting functions — versatile cutting for any material
- Creasing roller included — cut and crease without changing tools
- Media up to 0.39" (10 mm) thick — cuts through board, foam, and more
- Vacuum hold-down system — securely holds materials in place for precise cuts
- Total solution ready — integrates into a complete on-demand goods and package production workflow
- FineCut9 software included — professional cutting software right out of the box
Backed by Alder Color Solutions' G7-certified color experts, you'll get hands-on support with installation, setup, and training so your shop hits the ground running.
Technical Specifications
| Effective Plotting Area | 610 × 510 mm | Max Media Width | 24.8" × 20.8" (630 × 530 mm) |
| Max Media Thickness | T / TD: 1" | RT / RC: 0.8" (RC: 10 mm / T: 2 mm) | Max Cut Speed | 16.5" (423.0 mm/s) |
| Max Cut Pressure | Eccentric: 1,000g | Tangential / Creasing: 1,500g | Cutter Types | Pen/swivel, High-pressure Tangential, Reciprocating |
| Interface | USB 2.0, RS-232C, Ethernet | Power Supply | Single-phase AC100–120V / AC220–240V, 145 VA or less |
| Power Consumption | 500W or less | Operating Environment | Temp: 41–95°F Humidity: 35–75% RH (non-condensing) |
| Dimensions (W×D×H) | 51.97" × 41.14" × 43.30" (132 × 104.5 × 110 cm) | Weight | 240.3 lbs (109 kg) |
| Certifications | VCCI Class A, FCC Class A, ETL UL 60950-1, CE (Machinery Directive, RoHS), CB, REACH | ||
