The Epson SureColor T2170 is an affordable, easy-to-use 24" desktop wide-format printer designed for architects, engineers, graphic artists, and product designers who need precise, professional output without a large footprint. With a sleek, minimal design that fits comfortably on a desktop or with an optional stand, the T2170 gets you up and printing in as little as 30 minutes right out of the box.
Powered by Epson's PrecisionCore MicroTFP printhead and UltraChrome XD2 pigment inks at up to 2400 dpi, the T2170 delivers sharp, precise blueprints, line drawings, and posters with reliable consistency. It handles rolls up to 24" wide and sheets up to 11" x 17" through the Auto Sheet Feeder — all in a compact package built for modern workspaces.
Why shops choose the Epson SureColor T2170:
- Compact desktop design — ultra-small footprint fits on a desktop or with optional stand (sold separately)
- Up to 2400 dpi precision — sharp, precise detail for blueprints, line drawings, and posters
- UltraChrome XD2 pigment inks — durable, vibrant prints with long-lasting color accuracy
- Versatile media handling — rolls up to 24" wide and sheets up to 11" x 17" via Auto Sheet Feeder
- Easy setup — up and running in as little as 30 minutes right out of the box
- 4.3" touchscreen — intuitive front-panel control and job management
- Wireless and wired connectivity — Wi-Fi, Wi-Fi Direct, Ethernet, and USB 3.0
- 1-year next-business-day on-site warranty — with toll-free phone support Monday through Friday
Eco Features
- ENERGY STAR qualified
- RoHS compliant
- Recyclable product
- Epson America is a SmartWay Transport Partner
What's In The Box
- SureColor T2170 Printer
- Full set of initial ink cartridges (CMY — 26 mL / Black — 50 mL)
- Start Here Poster
- User Guide
- AC Power Cable
Note: Media is not included with the printer. Optional stand sold separately.
Backed by Alder Color Solutions' G7-certified color experts, you'll get hands-on support with installation, color profiling, and training so your shop hits the ground running.
Technical Specifications
| Print Technology | PrecisionCore MicroTFP 4-channel drop-on-demand printhead | Max Resolution | 2,400 x 1,200 dpi |
| Print Speed | A1/D-size print in 43 seconds | Min Droplet Size | 4 picoliters — Variable Droplet Technology (up to 3 sizes per line) |
| Nozzle Configuration | 800 nozzles x 4 channels (color and monochrome) | Ink Type | UltraChrome XD2 Pigment — C, M, Y, K |
| Max Paper Width | 24" | Min Paper Width | Roll: 13" | Sheet: 8.27" |
| Sheet Loading | Auto Sheet Feeder up to 11"x17" | Single sheet top-loading up to 24" | Roll Media | Up to 24" wide | 2" core | Max outer diameter 4.3" | Up to 8.6 mil thick |
| Roll Cutting | High-speed internal rotary cutter — auto or manual | Display | 4.3" touchscreen |
| Printer Language | ESC/P Raster, HP-GL/2, HP RTL | Interface | USB 3.0, Wi-Fi (802.11 b/g/n), Wi-Fi Direct, Ethernet (1000/100/10 Base-T) |
| OS Compatibility | macOS 10.7–10.13 | Windows 7 / 8.1 / 10 (32 & 64-bit) | Power Supply | AC 110–240V, 50/60Hz, 1.4A |
| Power Consumption | Printing: 28W | Ready: 8W | Sleep: 1.6W | Off: 0.2W | Sound Level | Operating: 49 dB(A) | Sleep: 32 dB(A) |
| Operating Environment | 50–95°F (10–35°C) | Recommended: 65–75°F (18–24°C) Humidity: 20–80% | Recommended: 45–60% |
Storage Environment | -4 to 104°F (-20 to 40°C) Humidity: 5–85% (non-condensing) |
| Dimensions (W×D×H) | Without stand: 38"×20"×9" (970×505×230 mm) With stand: 38"×28"×36" (970×696×913 mm) |
Weight | Without stand: 60 lbs (27 kg) With stand: 84 lbs (38 kg) |
| Certifications | UL (MET), FCC Class A, CSA, CE, EMC, ENERGY STAR, RoHS | ||
Ink Reference
| UltraChrome XD2 Ink | Black | Cyan | Magenta | Yellow |
|---|---|---|---|---|
| 26 mL Cartridge | — | T40V220 | T40V320 | T40V420 |
| 50 mL Cartridge | T40V120 | T40W220 | T40W320 | T40W420 |
| 80 mL Cartridge | T40W120 | — | — | — |
